400GE IDC / Cloud / DCI networks 400GE Backbone / (Ultra) Long-haul networks
• Hot-pluggable QSFP-DD package • Compliant with QSFP-DD MSA • Compliant with IEEE 802.3bs • Supports 425Gb/s data rate • Maximum link up to 40km • Operating temperature range: 0~70℃ • Built-in digital diagnostic functions • RoHS compliant
| P/N | Description | Data Rate | Distance | Wavelength | Case Temp.(℃) | Connector | Output Power(dBm) | Rec. Sens.(dBm) |
|---|---|---|---|---|---|---|---|---|
| QDDD5O-CMLRH85 | QSFP-DD SR8 | 8x50Gbps | 100m | 850nm | 0 ~ 70 | MTP/MPO | -6~4 | -7.9 |
| QDDDCQ-CSLRS31 | QSFP-DD DR4 | 4x100Gbps | 500m | 1310nm | 0 ~ 70 | MTP/MPO | -2.9~4 | -4.4 |
| QDDDCQ-CSLRMC | QSFP-DD FR4 | 4x100Gbps | 2km | 1271/1291/1311/1331nm | 0 ~ 70 | LC/UPC | -3.3~3.5 | -4.6 |
| QDDDCQ-CSLRCC | QSFP-DD LR4 | 4x100Gbps | 10km | 1271/1291/1311/1331nm | 0 ~ 70 | LC/UPC | ||
| QDDDCQ-CSLREC | QSFP-DD ER4 | 4x100Gbps | 40km | 1271/1291/1311/1331nm | 0 ~ 70 | LC/UPC | 0.4~6.5 | -16.5 |
